Brother MFC-L8600CDW - Harness Routing

To Next Page

To Previous Page

3-10

Confidential

7. HARNESS ROUTING

Harness colors may be changed for any reason.

1 Laser Unit

Hook

“A”

A view

Front

Main PCB ASSY

Hook

Front

Hole

Wireless LAN cable rack

Laser unit flat cable

Laser unit

Wireless LAN cable rack

Main PCB ASSY

CN7

CN8

Polygon motor harness (WH)

Core
