Fig. 3-80

■ A4 model/Legal model

(2) Remove the Gear cover from the ADF unit.

Fig. 3-81

Assembling Note:

When assembling the Gear cover, take care not to accidentally damage the Hooks

shown in the figure.

Hook

Gear cover

Hook

ADF unit

Gear cover

Hook
