Brother MFC-L8600CDW Service Manual

5-68
Confidential
1.3.36 Sending of communication log information to telephone line
(Function code 87)
<Function>
This function is used to send the error list to service personnel at a remote service station
when a fax communication problem has occurred in the user's machine. Receiving the error
list allows the service personnel to analyze the problem current in the user's machine.
<Operating procedure>
- Service side
(1) Make a call from the machine on the service side to the user’s machine.
-User side
- Service side
(5) When the user side starts sending the error list, press the Start key.
“Send or Receive? / 1.Send 2.Receive” is displayed on the LCD.
(6) Press the 2 key. The machine starts receiving the error list.
(2) Hold down the Home key in the ready state until the display on the LCD changes.
Memo:
If you c
annot find the Home key, press the Toner key,
and the Home key lights up.
(3) Hold down the blank box at the bottom on the LCD until the display on the LCD changes.
(4) Press the *, 0, #, 8 and 7 keys in this order. “SENDING P.01” is displayed on the LCD, and
the error list is sent. When the machine finishes sending the error list, it returns to the
ready state.

Brother MFC-L8600CDW Specifications

General

Type	all in one
Color	white
Tray Capacity	300
Automatic Document Feeder Capacity	35 sheets
Paper Size	8.5" x 14"
Paper Handling	up to 300 sheets
Color Print Speed	30 pages per minute
Mono Print Speed	30 pages per minute
Print Resolution Color	up to 2400 x 600
Maximum Number of Pages Per Month	up to 40, 000
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Cartridges	tn331bk, tn336bk, tn331y, tn336y, tn331m, tn336m, tn331c, tn336c, dr331cl
Number Of Cartridges	4
Internal Memory	yes
Network	wired, wireless
Connectivity	usb, google cloud print
OS Compatibility	windows, mac os, linux
Mobile Devices Connection	yes

Weight and Dimensions

Height	16.1 inches
Width	19.8 inches
Net Weight	63.5 pounds
