Brother MFC-L8600CDW Service Manual

2-56
Confidential
■ Error code 6300
The waste toner sensor detected that no waste toner box was set.
< User Check >
- Re-insert the waste toner box in the correct position.
■ Error code 6400
The registration mark sensor detected that no belt unit was set.
< User Check >
- Re-insert the belt unit.
No Waste Toner
Install the Waste Toner Box.
Step Cause Remedy
1 High-voltage power supply PCB
failure
Replace the high-voltage power supply
PCB ASSY.
2 Main PCB failure Replace the main PCB ASSY.
No Belt Unit
Open the Front Cover, pull out all Drum Units completely and install the Belt Unit.
Step Cause Remedy
1 Connection failure of the
registration mark L PCB harness
Reconnect the registration mark sensor L
PCB harness.
2
Registration mark L sensor failure Replace the registration mark sensor unit.
3 Main PCB failure Replace the main PCB ASSY.
