Brother TD-4520DN User Manual

Home > Routine Maintenance > Clean Your Printer
Clean Your Printer
We recommend cleaning your printer on a regular basis to maintain its correct performance.
Always disconnect the printer from any power source before cleaning.
>> Clean the Exterior of the Unit
>> Clean the Label Output Slot
>> Clean the Roller
>> Clean the Print Head
Clean the Exterior of the Unit
• Wipe any dust and marks from the main unit using a soft, dry cloth. Use a cloth slightly damp with water on
difficult to remove marks.
IMPORTANT
Do not use paint thinner, benzene, alcohol or any other organic solvent. These may deform or damage
the printer case.
Clean the Label Output Slot
• If adhesive residue gets attached to the Label Output Slot, it may cause label jams. Clean the Label Output
Slot with a dry cotton swab.
IMPORTANT
Do not use alcohol to clean the Label Output Slot.
NOTE
- Always remove the ejected labels from the Label Output Slot. If the slot becomes blocked, label jams
may occur.
99

Brother TD-4520DN Specifications

General

Font styles	Brougham, Brussels, Helsinki, Letter Gothic, San Diego
Flash memory	64 MB
Internal memory	256 MB
Number of fonts	6
Built-in barcodes	CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E
Page description languages	CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II
Color	No
Text style	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Mirror printing	Yes
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Minimum print length	17 mm
Maximum printing width	- mm
Product color	Grey, White
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	20 - 85 %
Operating relative humidity (H-H)	5 - 40 %
Cables included	AC, USB
USB 2.0 ports quantity	1
Connectivity technology	Wired
LED indicators	Error, Power, Status
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Networking features	10/100BASE-TX
Number of languages	18
Core diameter	12.7 mm
Maximum label width	118 mm
Maximum roll diameter	127 mm
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Quantity per pack	1 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	155 mm
Width	108 mm
Height	224 mm
Weight	2080 g
