Parts Description
Front
2
3
1
8
9
7 6
4
5
1. Label Output Slot
2. Roll Compartment Cover
3. Tear Bar
4. Status LED
5. Roll LED
6.
(Function) Button
7. (Feed) Button
8. (Power) Button
9. Power LED
To pause printing, press any button. Press the button again to resume printing. Printing can be paused only
after each full page has been printed and cannot be paused on the final page or between pages.
Rear
1
3
4
2
1. Power Port
