Brother TD-4520DN User Manual

Home > Update > Update the Firmware
Update the Firmware
• Before updating the firmware, you must install the printer driver.
• Do not turn the power off when transferring data or updating firmware.
• If another application is running, exit the application.
1. Turn the printer on and connect the USB cable.
2. Start the P-touch Update Software.
• Windows 10/Windows Server 2016:
Click Start > Brother P-touch > P-touch Update Software, or double-click the P-touch Update
Software icon on the desktop.
• Windows 8/Windows 8.1/Windows Server 2012/Windows Server 2012 R2:
Click the P-touch Update Software icon on the Apps screen, or double-click the P-touch Update
Software icon on the desktop.
• Windows 7/Windows Server 2008/Windows Server 2008 R2:
Click Start > All Programs > Brother P-touch > P-touch Update Software, or double-click the P-touch
Update Software icon on the desktop.
3. Click the Machine update icon.
4. Select the Printer option, make sure the machine is connected correctly, and then click OK.
5. Select the Language option, select the check box next to the firmware you want to update to, and then click
Transfer.
73

Brother TD-4520DN Specifications

General

Font styles	Brougham, Brussels, Helsinki, Letter Gothic, San Diego
Flash memory	64 MB
Internal memory	256 MB
Number of fonts	6
Built-in barcodes	CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E
Page description languages	CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II
Color	No
Text style	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Mirror printing	Yes
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Minimum print length	17 mm
Maximum printing width	- mm
Product color	Grey, White
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	20 - 85 %
Operating relative humidity (H-H)	5 - 40 %
Cables included	AC, USB
USB 2.0 ports quantity	1
Connectivity technology	Wired
LED indicators	Error, Power, Status
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Networking features	10/100BASE-TX
Number of languages	18
Core diameter	12.7 mm
Maximum label width	118 mm
Maximum roll diameter	127 mm
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Quantity per pack	1 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	155 mm
Width	108 mm
Height	224 mm
Weight	2080 g
