Brother TD-4520DN User Manual

Home > Network > Learn about Network Management Software and Utilities
Learn about Network Management Software and Utilities
Related Models: TD-4420DN/TD-4520DN
Web Based Management
Web Based Management is a utility that uses a standard web browser to manage your machine using the Hyper
Text Transfer Protocol (HTTP) or Hyper Text Transfer Protocol over Secure Socket Layer (HTTPS). Type your
machine's IP address into your web browser to access and change your print server settings.
BRAdmin Light (Windows)
BRAdmin Light is a utility for the initial setup of network-connected Brother printers. This utility can search for
Brother printers on your network, view their status and configure the basic network settings, such as IP address.
Go to your model's Downloads page on the Brother support website at
support.brother.com to download
BRAdmin Light.
If using a firewall, anti-spyware, or antivirus software, temporarily disable them. When you are sure you can
print, re-enable them.
BRAdmin Professional (Windows)
BRAdmin Professional is a utility for more advanced management of network-connected Brother printers. This
utility can search for Brother printers on your network and view their status from an easy-to-read Windows
Explorer-style screen that changes colour to identify the status of each printer. You can configure network and
printer settings, and update printer firmware from a Windows computer on your LAN. BRAdmin Professional can
also log activity of Brother printers on your network and export the log data.
Go to your model's Downloads page on the Brother support website at support.brother.com to download the
latest version of Brother's BRAdmin Professional utility.
• The node name appears in the current BRAdmin Professional window.
The default node name is "BRNxxxxxxxxxxxx". (“xxxxxxxxxxxx” is based on the printer's MAC Address /
Ethernet Address.)
• If using a firewall, anti-spyware, or antivirus software, temporarily disable them. When you are sure you
can print, re-enable them.
Related Information
• Network
69

Brother TD-4520DN Specifications

General

Font styles	Brougham, Brussels, Helsinki, Letter Gothic, San Diego
Flash memory	64 MB
Internal memory	256 MB
Number of fonts	6
Built-in barcodes	CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E
Page description languages	CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II
Color	No
Text style	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Mirror printing	Yes
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Minimum print length	17 mm
Maximum printing width	- mm
Product color	Grey, White
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	20 - 85 %
Operating relative humidity (H-H)	5 - 40 %
Cables included	AC, USB
USB 2.0 ports quantity	1
Connectivity technology	Wired
LED indicators	Error, Power, Status
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Networking features	10/100BASE-TX
Number of languages	18
Core diameter	12.7 mm
Maximum label width	118 mm
Maximum roll diameter	127 mm
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Quantity per pack	1 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	155 mm
Width	108 mm
Height	224 mm
Weight	2080 g
