Home > Printer Settings > Change Printer Settings Using Web Based Management
Change Printer Settings Using Web Based Management
Related Models: TD-4420DN/TD-4520DN
You can use a standard web browser to change your print server settings using the Hyper Text Transfer Protocol
(HTTP) or Hyper Text Transfer Protocol over Secure Socket Layer (HTTPS).
When using Web Based Management, the following operations are available:
• Displaying your printer status information
• Changing network settings, such as TCP/IP information
• Displaying software version information of the printer and print server
• Changing network and printer configuration details
• We recommend Microsoft Internet Explorer 11/Microsoft Edge for Windows. Make sure that JavaScript
and Cookies are always enabled in whichever browser you use.
• The default login password to manage printer settings is initpass. We recommend you change it to
protect your printer from unauthorised access.
To use Web Based Management, your network must use TCP/IP, and the printer and computer must have a valid
IP address.
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
If you are using a Domain Name System or enable a NetBIOS name, you can type another name, such as
"SharedPrinter" instead of the IP address.
• For example:
https://SharedPrinter
If you enable a NetBIOS name, you can also use the node name.
• For example:
https://brnxxxxxxxxxxxx
3. If the machine prompts you for a password, type it, and then click .
4. Change the print server settings.
Every time you access Web Based Management, type the password in the Login field, and then click . After
configuring the settings, log out by clicking .
Related Information
• Printer Settings
• Set or Change a Login Password for Web Based Management
95

Brother TD-4520DN Specifications

General

Font styles	Brougham, Brussels, Helsinki, Letter Gothic, San Diego
Flash memory	64 MB
Internal memory	256 MB
Number of fonts	6
Built-in barcodes	CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E
Page description languages	CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II
Color	No
Text style	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Mirror printing	Yes
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Minimum print length	17 mm
Maximum printing width	- mm
Product color	Grey, White
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	20 - 85 %
Operating relative humidity (H-H)	5 - 40 %
Cables included	AC, USB
USB 2.0 ports quantity	1
Connectivity technology	Wired
LED indicators	Error, Power, Status
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Networking features	10/100BASE-TX
Number of languages	18
Core diameter	12.7 mm
Maximum label width	118 mm
Maximum roll diameter	127 mm
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Quantity per pack	1 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	155 mm
Width	108 mm
Height	224 mm
Weight	2080 g
