Brother TD-4520DN User Manual

Home > Transfer Templates to the Printer (P-touch Transfer Manager) (Windows) > Transfer Templates to
the Printer Using P-touch Transfer Manager (Windows) > Backup Templates or Other Data Saved in the
Printer (Windows)
Backup Templates or Other Data Saved in the Printer (Windows)
You can retrieve templates or other data saved in the printer and save it on the computer.
• Backed up templates or other data cannot be edited on the computer.
• Depending on the printer model, backed up templates or data may not be transferable between different
models.
1. Connect the computer and the printer and turn the printer on.
The printer model name appears next to a printer icon in the folder view. If you select the printer in the folder
view, the current templates and other data stored in the printer appear.
2. Select the printer to back up from, and then click Backup.
A confirmation message appears.
3. Click OK.
A new folder is created under the printer in the folder view. The folder name is based on the date and time of
the backup. All of the printer's templates and other data are transferred to the new folder and saved on the
computer.
Related Information
• Transfer Templates to the Printer Using P-touch Transfer Manager (Windows)
55

Brother TD-4520DN Specifications

General

Font styles	Brougham, Brussels, Helsinki, Letter Gothic, San Diego
Flash memory	64 MB
Internal memory	256 MB
Number of fonts	6
Built-in barcodes	CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E
Page description languages	CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II
Color	No
Text style	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Mirror printing	Yes
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Minimum print length	17 mm
Maximum printing width	- mm
Product color	Grey, White
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	20 - 85 %
Operating relative humidity (H-H)	5 - 40 %
Cables included	AC, USB
USB 2.0 ports quantity	1
Connectivity technology	Wired
LED indicators	Error, Power, Status
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Networking features	10/100BASE-TX
Number of languages	18
Core diameter	12.7 mm
Maximum label width	118 mm
Maximum roll diameter	127 mm
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Quantity per pack	1 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	155 mm
Width	108 mm
Height	224 mm
Weight	2080 g
