Brother TD-4520DN User Manual

• Received Data Size: Printing starts when the number of characters specified here is received. However,
delimiters are not counted in the number of characters.
5. Character Code Table
Selects one of the character code sets.
6. International Character Set
Lists character sets for specific countries. The following codes vary depending on the selected country:
23h 24h 40h 5Bh 5Ch 5Dh 5Eh 60h 7Bh 7Ch 7Dh 7Eh
To change the characters, see the P-touch Template Manual/ Command Reference (English only). You
can download the latest version from the Brother support website at
support.brother.com/manuals.
7. Command Prefix Character
Specifies the prefix character code identifying commands used in P-touch Template mode.
8. Non-Printed Character
Characters specified here are not printed when data is received (maximum of 20 characters).
9. Available Return Code
The line feed code is used when feeding data to indicate that the following data should be moved to the next
line in a text object. Select one of four line feed codes or type the line feed code you want (maximum of 20
characters).
10. Replace FNC1
Replaces GS codes with FNC1.
11. Number of Copies
Sets the number of copies (maximum of 99 copies).
12. Auto Cut
Specifies if the printer should cut the labels and how many labels to print before cutting (maximum of 99
labels).
13. Inverted 180 Degrees
If this check box is selected, the data will be printed after it has been rotated 180 degrees.
14. Communication Settings
Sets the parameters for serial communication.
15. Default
Returns all setting values in the P-touch Template Settings dialog box to the default values.
16. Cancel
Cancels the settings and closes the dialog box. The settings remain unchanged.
17. Set
Applies the settings to the printer. To save the specified settings to a command file to reuse in the future,
select the Save in Command File command from the drop-down list.
The saved command file can be used with the mass storage mode to apply the settings to a printer.
Related Information
• Change Printer Settings Using the Printer Setting Tool (Windows)
Related Topics:
• Print Using USB Interface (Mass Storage Mode)
88

Brother TD-4520DN Specifications

General

Font styles	Brougham, Brussels, Helsinki, Letter Gothic, San Diego
Flash memory	64 MB
Internal memory	256 MB
Number of fonts	6
Built-in barcodes	CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E
Page description languages	CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II
Color	No
Text style	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Mirror printing	Yes
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Minimum print length	17 mm
Maximum printing width	- mm
Product color	Grey, White
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	20 - 85 %
Operating relative humidity (H-H)	5 - 40 %
Cables included	AC, USB
USB 2.0 ports quantity	1
Connectivity technology	Wired
LED indicators	Error, Power, Status
Languages support	CHI (SIMPL), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
Networking features	10/100BASE-TX
Number of languages	18
Core diameter	12.7 mm
Maximum label width	118 mm
Maximum roll diameter	127 mm
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Quantity per pack	1 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	155 mm
Width	108 mm
Height	224 mm
Weight	2080 g
