Ref Description P/N Notes
1 START – STOP Switch 5010021
2 Key Switch/ STOP Switch 5010020
3 Dual Binacle Mount Remote Control 766564
4 *Remote Control Harness – Included with Remote Control
5 Key Switch Switch Connection –
6 START – STOP Switch Connection –
7 Remote Control to NMEA 2000 Network Connection –
8 Accessory Power Out (12 VDC) –
9 Remote Control Network Connection –
10 Network Power In (12 VDC) –
11 Oil Level 1 & 2 –
12 Fuel Level 1 & 2 –
13 Trim Switch Connection –
14 Terminator Kit 764155
15 Power Node and Tee Kit 767433 3 Amp fuse
16 Connection to NMEA 2000 Digital Display –
17 Connection to NMEA 2000 Network –
18 NMEA 2000 Buss Cables –
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
19 Backbone Buss Cables –
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions –
1 ft. (0.3 m) 587176
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
20 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
20 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
21 Fuel Tank Sender –
22 6–Port Hub 587172
23 Connection to NMEA 2000 Accessories – GPS, Triducer, etc.
24 Battery Cable, 10 ft. (3.0 m) 587205
24 Battery Cable, 15 ft. (4.5 m) 587301
24 Battery Cable, 20 ft. (6.0 m) 587302
* "Y" Harness (Optional accessory) 587230
Use to power digital displays & accessories to be
powered when the key switch is ON.
