75
Outboard Rigging
Buss Cable, Hoses, and Wire Routing and Connections
4
ALL Models
Use Evinrude Diagnostics software to set the
water pressure transducer.
Rigging Hose and Cover
Installation
Install the rigging hose to the entry port of the
cable entryway. Install the cover into place below
the cable entryway.
Turn the cable entryway end cap 90° to lock it into
place.
1. 50 psi Transducer
009237
1. Rigging hose installation
2. Cover
009094
1. Rigging center end cap
009391
