Application:
2 Stations
3 Evinrude E-TEC G2 outboards
2 DPS, 1 non-DPS
2 standard rotation, 1 counter-rotation
Or, 2 counter rotation, 1 standard rotation
Mechanical Tie Bars
Ref Description P/N Notes
1 Helm, Upper Station (with Vented Fill Plug) –
2 Steering Hose, Starboard Upper Helm to Starboard Tee Fitting
3 Steering Hose, Port – Upper Helm to Port Tee Fitting
4 Helm, Lower Station (with Non-Vented Fill Plug) –
5 Compensating Line – Upper to Lower Helm
6 Steering Hose, Starboard – Tee Fitting - Lower Helm to Starboard Tee Fitting
7 Steering Hose, Port – Tee Fitting - Lower Helm to Port Tee Fitting
8 Tee-Fitting –
9 Steering Hose, Starboard – Tee Fitting to Tee Fitting
10 Steering Hose, Port – Tee Fitting to Tee Fitting
11 Steering Hose, Starboard –
Tee Fitting to Starboard Outboard, Starboard
12 Steering Hose, Port – Tee Fitting to Starboard Outboard, Port Connection
13 Steering Hose, Starboard – Tee Fitting to Center Outboard, Starboard Connection
14 Steering Hose, Port – Tee Fitting to Center Outboard, Port Connection
15 By-Pass Hose – Non-IPS outboard
16 Tie Bar Kits –
Three/Four Outboard, 24 to 29 inch spacing 766608
Three/Four Outboard, 29 to 36 inch spacing 766609
