Ref Description P/N Notes
1 ICON Digital Displays and Gauges – Refer to Parts & Accessories Catalog
2 Tachometer Harness 765499
3 Harness, 2 inch Gauge –
12 in. (30 mm) 765512
24 in. (61 mm) 765514
30 in. (76 mm) 765515
4 Speedometer Harness 765509
5 Power Node and Tee Kit 767433 3 Amp fuse
6 * "Y" Harness 587230 (1) "Y" harness included with P/N 767433
7 Terminator Kit 764155
8 NMEA 2000 Network Connection –
9 NMEA 2000 Buss Cables –
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
10 Connection to NMEA 2000 Accessories – GPS, Triducer, etc.
11 START – STOP Switch 5010021
12 Key Switch/ STOP Switch 5010020
13 Dual Binacle Mount Remote Control 766564
14 *Remote Control Harness – Included with Remote Control
15 Backbone Buss Cables –
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions –
1 ft. (0.3 m) 587176
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
16 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
16 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
17 Fuel Tank Sender –
18 6–Port Hub 587172
19 Battery Cable, 10 ft. (3.0 m) 587205
19 Battery Cable, 15 ft. (4.5 m) 587301
19 Battery Cable, 20 ft. (6.0 m) 587302
