Ref Description P/N Notes
1 Digital to Analog Converter 766287
2 *Harness (Single or Port Engine/Tachometer) 587212 Included with Converter
3 Trim Send Connection –
4 Non-SystemCheck Connection –
5 SystemCheck Tachometer Connection –
6 Warning Horn Connection –
7 Harness (Dual Engine/Starboard Tachometer) 587213
installation)
8 Trim Send Connection – Optional
9 Non-SystemCheck Connection – Optional
10 SystemCheck Tachometer Connection – Optional
11 Warning Horn Connection – Optional
12 Converter Power Connection (12 VDC) –
13 NMEA 2000 Network Connection –
14 Power Node and Tee Kit 767433 3 Amp fuse
15 * "Y" Harness 587230
16 Terminator Kit 764155
17 NMEA 2000 Network Connection –
18 NMEA 2000 Buss Cables –
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
19 NMEA 2000 Network Connection (to engine) 764155
20 Key Switch (OFF – ON – START) 768746
21 Remote Control – Refer to Parts & Accessories Catalog
22 *Harness – Included with Remote Control
23 Accessory Power Out (12 VDC) –
24 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
24 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
25 Fuel Tank Sender –
26 Battery Cable, 10 ft. (3.0 m) 587205
26 Battery Cable, 15 ft. (4.5 m) 587301
26 Battery Cable, 20 ft. (6.0 m) 587302
