HOW TO REPLACE FUSES AND LIGHTS
rmr2011-079-001_b
1. Adjustment cable retaining nut
7. Remove all 4 headlight retaining
screws.
rmo2010-001-076_a
1. Retaining screws
8. Pull tabs apart to unlock cover.
rmo2010-001-077_a
1. Headlight cover
2. Pull tabs apart
9. Pull cover out.
10. Disconnect the bul
b connector.
rmo2010-001-078_a
1. Unplug connector
11. Turn the bulb counterclockwise to
unlock it.
rmo2010-001-079_a
1. Turn counterclockwise
12. Pull bulb out.
13. Insert the new bulb into its socket
then turn clockwise to lock it in po-
sition.
NOTICE
Never put your fingers
on a new halogen bulb. This would
shorten its life.
156
