BRUSTOR B200 - Louvres with LED Strip and Connection

OL-B200(XL)-12
6.e CONNECTING THE LOUVRES
› Slide the covers onto the louvreholders, and screw them.
6.d LOUVRES WITH LEDSTRIP
4x DIN7504 4.2x13
› Also place the PVC covers onto the First Louvres.
› Place the louvres as described above.
› Put the cables inside the louvreholder, if necessary put the cables through the first louvres until it ends
up in the mainhousing.
