BRUSTOR B200 - Overview

OL-B200(XL)-01
Top cover vertical pole
Corner drain
Single
Couple
0. OVERVIEW
› Check if all parts are present, and check if the dimensions are as ordered
Louvres
Horizontal coupling profile
Assembled motor
(premounted)
Drain
(Tube D50 not
delivered)
Reinforcement
Screen
Rain gutter
Motor control unit
(Pre-assembled)
Groundanchor
Pole Support (standard)
Floorplate 20x20
Vertical pole
(pre-assembled screenguide)
Cover vertical pole
Fixation for groundanchor
or floorplate
Louvre holder + cover
Pole Support coupled unit (standard)
Cover vertical coupling pole
(pre-assembled screenguide)
Vertical coupling pole
Support for ground anchor
or floor plate for coupling pole
