BRUSTOR B200 - Placing Louvres in Assemblies

OL-B200(XL)-10
› Place the louvres in the provided holes.
› The longest axles should be placed at the highest side.
› Press the axle in the L2 side, and turn the louvre into the louvre holder L1.
SINGLE
› The louvres are mounted in the following order:
SINGLE MOD
ULE
WITH ROOF IN 2
PARTS
COUPLE
SINGLE ROOF
6.c PLACE THE LOUVRES
PUSH
PUSH
FRONT VIEW
TOP VIEW
TURN
L2
L1
L2
L1
