OL-B200(XL)-19
› Turn the rain gutters in position starting from the top. (1)
› Make sure the gasket is not damaged!
› First close the roof so the louvres and motor are not interfering.
› Screw the corner piece (M6 x 40) (2).
› While screwing, push the corner piece firmly against the rain gutters. (3)
12.b RAIN GUTTER
13. FINISHING
13.a DRAIN
Not provided
50
Push firmly !
› Place the necessary parts at every draining point.
2”
