BRUSTOR B200 - Wall Fixation Support Placement

OL-B200(XL)-03
L
w
W - 9-7/8”
H-4-3/8”
4-7/8” 4-7/8”
1.b WALL FIXATION
1/4”
L
W
W - 9-7/8”4-7/8” 2”
1/4”
2”
SINGLE
COUPLE
H
1/4”
› Use the dimensions mentioned above, but add 1/4” next to the wall.
