BRUSTOR B200 - Placing the Supports; Stand Alone Support Placement

OL-B200(XL)-02
1. PLACING THE SUPPORTS
W
L
1.a STAND ALONE
=
W
L
W
L
L - 3-1/2”
W - 3-1/2”
W - 3-1/2”
L - 3-1/2”
=
=
=
=
Pole Support Ground Anchor Floorplate 20x20
W
L
W
L
W - 1-3/4”
L
L - 3-1/2”
W - 1-3/4”
L - 3-1/2”
W
=
=
=
=
Pole Support Ground Anchor Floorplate 20x20
SINGLE
COUPLE
=
W - 3/8”
L - 3/8”
L - 3/8”
L - 3/4”
› Place the supports as indicated on the following drawings.
› Check the diagonals, the difference should not be more than 1/4”.
