BT NetAgent Series User Manual

BT UPS Enterprise SNMP Agent
Issued by: BT
Version no: 6.1
Date: March 2019
Page 11 of 103
Flashing
Flashing
Solid ON
Writing data to flash memory
Green light : Power state
Red light : Connection state with UPS
Fig.2 NetAgent II Out looking
1.3.5 NetAgent Mini OutLook
Light signal application of NetAgent Mini - Status LED
Light color
Signal definition
Condition description
Green
Power state
On: Normal power
Red
Connection state with UPS
Flash: no connection with UPS
Orange
Correspondence state
Light flashes when Netagent transmits
command to UPS
Light signal application of NetAgent Mini - LAN Port LED
Light color
Condition description
Green
On: Internet correspond speed is 100M Flash: Data transmmiting
Yellow
On: Internet correspond speed is 10M Flash: Data transmmiting
Fig.3 NetAgent Mini Out looking
1.4 NetAgent9 Models
1.4.1 NetAgent 9 Models
NetAgent 9 Model
To LAN (LAN Port LED)
Status LED
NetAgent Mini Internal Module
To UPS
To DC adapter
To LAN (LAN Port LED)
To UPS
Status LED
NetAgent Mini External
