BT UPS Enterprise SNMP
Agent
Issued by:
BT
Version
no:
6.1
Date:
March 2019
Page
17
of
103
Green
Power state
On: Normal power
Red
Connection state with UPS
Flash: no connection with UPS
Orange
Correspondence state
Light flashes when Netagent transmits
command to UPS
Light signal application of
NetAgent 9 Mini
-
LAN Port LED
Light color
Condition description
Green
On: Internet c
orrespond speed i
s 100M Flash: Dat
a transmmiting
Yellow
On: Internet c
orrespond speed i
s 10M Flash: Dat
a transmmiting
16
18
