Operation
SMART KNIT - 3.17 -
OUTPUT - Configuration of Output Signals
SETUP
$
$$
$
CONFIG
$
$$
$
OUTPUT
This function allows you to configure each of the 2 output signals (ST-1 ÷ ST-2) as
either normally closed (NC) or normally open (NO) contact.
to activate the function (parameter ST-1).
to select NO or viceversa.
to confirm the choice and move to parameter ST-2.
to select NO or viceversa.
to confirm the choice
to move to the TEST function.
to return to CONFIG menu.
TEST - Test Function and Sensor Firmware Update
SETUP
$
$$
$
CONFIG
$
$$
$
TEST
The TEST function allows you to perform 3 diagnostics sub-functions:
- COM = Communication test between SMART KNIT and SM-DIN
- FEEDS = Test of sensors associated with the machine feeds
- SENSORS = Test of individual sensors
and a function for firmware upgrading on IS3 sensors (UPG).
to activate the Test function.
to select the desired sub-function:
- COM
-
FEEDS
-
SENSORS
-
UPG
