Summary Tables of Style Programming Parameters
SMART MATRIX WINDINGFEEDER - 42 -
Parameters programmable on ADV window (STYLE EDIT function)
Parameter Possible range Default Meaning
*
TENSION ERR. 0.1 to 50 or “A” 0.5 Tolerance beyond which an alarm will be generated P1.2
TIME ALARM 0.1 to 50, “A”, OFF 2.0 Time for which the tension may exceed the tolerance. P1.3
K-PID 1 to 5 3 Constant value of the device reactivity P2.4
RAMP UP 1 to 250 40 Tension increase ramp P2.2
RAMP DOWN 1 to 250 40 Tension decrease ramp P2.3
K FACTOR -20.0 to 20.0
0.0
TARGET correction factor compensating possible yarn slipping
(**)
-
AUTO OFFSET
disabled
, enabled ;
Auto Offset function enabled/disabled P3.1
EDITOR LOCKED
disabled
, enabled ;
Parameter progr. on WINDINGFEEDER enabled/disabled -
WINDINGFEEDER OFF
disabled
, enabled ;
WINDINGFEEDER device enabled/disabled -
YARN TYPE ALL YARNS, ELASTIC
ALL YARNS
Type of yarn used (normal or elastic) P4.5
APPLICATION REWIND 1/2, WARP 1/2
REWIND1
Type of application used P4.4
* Corresponding parameter of WINDINGFEEDER device.
(**) Unlike the TARGET CALIBRATION, which can be set for each individual device, the K FACTOR
parameter is the same for all the involved devices. Setting a negative value, the TARGET value will be
decreased by the set percentage; otherwise, setting a positive value, the TARGET value will be increased by
the set percentage.
Parameters programmable on CONFIG window (STYLE EDIT function)
Parameter Possible range Default Meaning
*
SENSOR TYPE 100 cN or 1000 cN 100 cN Type of TS44 sensor P4.2
ROTATION CW or CCW CW Motor rotation direction: CW or CCW P4.1
UNICO MODE AUTO or OFF AUTO Automatic detection of option intelligent accessory P4.8
ALARM STOP NO or NC NO Stop Alarm Output polarity P4.7
TARGET STOP NO or NC NO Stor Target Output polarity P4.7
P1/P2 INPUT NO or NC NO Polarity of P1 e P2 inputs P4.7
RESET INPUT NO or NC
NO Polarity of Reset input P4.7
EXC NO or NC NO Polarity of EXC input P4.7
DISPLAY NORMAL or FLIP NORMAL Image rotation of WINDINGFEEDER device -
* Corresponding parameter of WINDINGFEEDER device.
For more detail about the indicated operation/control parameters, please refer to WINDINGFEEDER
manual.
