Summary Tables of Style Programming Parameters
SMART MATRIX WINDINGFEEDER - 41 -
Summary Tables of Style Programming Parameters
Parameters programmable on PROFILE window (STYLE EDIT function)
Parameter Possible range Default Meaning
*
TENSION MODE PROFILER or P1/P2
PROFILER
Choice between PROFILER or P1/P2 operating modes
-
START METER 1 to 50,000 or OFF OFF No meters for which the START TENS will be applied.
-
START TENS 0.2 to 99.5 or OFF 20.0 Yarn tension at the position Startup
-
WORK TENS 0.2 to 99.5 10.0 Yarn tension after the No meters defined in START METER P1.1
INC/DEC METER 1 to 100.000 or OFF OFF Increment/decrement steps of “WORK TENS”
-
INC/DEC TENS -99.5 to 99.5 or OFF 0.1 Amount of increment/decrement of “WORK TENS”
-
TARGET METER 1 to 1.000.000 or OFF (**) 50,000 Total number of yarn meters to wind.
-
TARGET TENS 0.2 to 99.5 or OFF OFF Yarn tension when reaching the TARGET
-
* Corresponding parameter of WINDINGFEEDER device.
Notes:
In the PROFILE window you may either enable or disable the TENSION PROFILER function, i.e. the
dynamic trend of the yarn feeding tension from the machine Startup (START TENS) up to the Target.
If you enable the PROFILE option in TENSION MODE, then the tension trend will depend on the values set
to the remaining parameters.
If, on the contrary, you set P1/P2 in TENSION MODE, then some parameters will automatically be disabled,
and the WINDINGFEEDER devices will work only with the tension values WORK TENS P1 (P1.1) and
WORK TENS P2 (P2.1).
For more details about the TENSION PROFILER function, please refer to the examples shown on next
pages.
(**)The value set on “TARGET METER” can be modified by the user (device by device), in such a way as to
compensate possible slipping between yarn and WINDINGFEEDER device wheel.
During the style saving, the question: “EDIT TARGET CALIBRATION?” will appear; by answering “YES” you
can introduce a correction factor (%) for each device.
