btsr ULTRAFEEDER - YTT Connection and Activation

YTT Device
- 5.2 - ULTRAFEEDER
Connection
The YTT device must be connected to the ULTRAFEEDER device using the MA8/10/2FE10/CAN cable, as
shown on the following figure:
MA8/10/2FE10/CAN cable
If the adapter cap is installed on the ULTRAFEEDER device connector (see: ULTREFEEDER device electrical
interface on chapter2), it is necessary to remove it to connect the MA8/10/2FE10/CAN cable.
ULTRAFEEDER
YTT
