Operation
- 3-18 - WINDINGFEEDER
P4.3
BAUDRATE
This parameter allows you to setup the communication speed on the
WINDINGFEEDER serial interface.
[Allowed values: 57600 or 115200]
or to choose the desired speed.
to confirm the speed shown on display and move to the next parameter.
P4.4
APPLICATION SELECTION
This function allows you to choose one of the pre-defined applications.
or to choose the desired option: REWIND1, REWIND2, WARP1 or WARP2.
to confirm the application shown on display and move to the next parameter.
P4.5
ELASTIC
This function allows you to set the yarn characteristics.
or to choose between ELASTIC * or ALL YARN options.
to confirm the application shown on display and move to the next parameter.
* The
ELASTIC mode allows a better handling of bare elastic yarns.
P4.6
LANGUAGE SELECTION
This function allows you to select the language used to display menu items,
messages and errors.
or to scroll forward/backward the list of available languages:
ITALIANO – ENGLISH – FRANCAIS – ESPANOL – DEUTSCH – JAPANESE
to confirm the language indicated on display and return to the beginning of P4
menu.
P4.7
SIGNAL POLARITY
This function allows you to setup the polarity of INPUT and STOP signals.
to toggle the INPUT signal between NO and NC.
to toggle the STOP signal between NO and NC.
to confirm the option shown on display and move to the next parameter.
 Both: Inputs and Outputs can be programmed as normally open (NO) or
normally closed (NC) contacts. The programming is global, i.e. every input
(and every output in the same way) operates as NO or NC, depending on the
selected option.
