btsr WINDINGFEEDER - TECHNICAL DATA AND INSTALLATION; Technical Specifications

Technical Data and Installation
WINDINGFEEDER - 2.1 -
2 – TECHNICAL DATA AND INSTALLATION
Technical Features
WINDINGFEEDER Device
Power supply voltage 24 VDC ± 10% or 24 VAC ± 20%
0.2 A (during normal operation);
1 A (under stress);
Maximum absorption
3 A (at start-up)
STOP Outputs: relay contacts (NO)
0.3 A 125 VAC
1 A 30 VDC
Opto-insulated Inputs
0-24 VDC
VIL Max 1.2 VDC
VIH Min 5 VDC
Max. voltage Iinputs,- Output) 30 VDC
Programmable yarn tension
0.5 ÷ 100.0 gr. (resolution 0.1 gr.) or
5 ÷ 1,000 gr. (resolution 1 gr.)
Depending on the type of TS44 sensor used
Programmable alarms 0.1 ÷ 10 sec.
Integrated keypad 3 push-buttons + STOP red LED
Signaling With LCD graphic display
Dimensions 290 x 86 x 94 mm
Operating temperature range 10° - 60 °C
Storage temperature -25° - +85° C
Tension range 0 / full scale
Useful tension range 0% - 95% full scale
Max applicable tension 10 times the full scale value
IS3x/TS Sensor
Power supply voltage 12 .. 24 Vdc ± 20%
Absorption 15 mA (max 20 mA)
STOP output
NPN
STOP output protection
Protection against over-voltages/short-
circuits
Maximum Current of STOP output
200 mA continuous; 500 mA peack
Reaction Delay
Programmable from 5 to 1,000 msec
Sensitivity
Programmable (10 levels)
Signaling
With integrated LEDs
Dimensions (mm)
15 x 15 x 36,5 (Narrow) - 25 x 15 x 36.5 (Wide)
Operating temperature range 10° - 60 °C
Storage temperature -25° - +85° C
TS44/xxxyRW Sensor
Power supply voltage 12 .. 24 Vdc ± 10%
Absorption 20 mA (max)
Analogue Output 100 mV - 10V
Analogue output resistance 1K Ohm
Operating temperature range 10° - 50 °C
Storage temperature -25° - +85° C
Tension range 0 - fondo scala
Useful tension range 0% - 95% fondo scala
Max applicable tension 10 volte il fondo scala
Drift error (a) 0.05% / °C
Repeatability error (b) 0.5%
Max linearity error (c) 2% (0 - fondo scala)
Signaling Mediante LED integrati
Dimensions 50 x 25 x 12.5 mm
