2-86 2005 Buell Firebolt: Chassis
HOME
Figure 2-116. Belt Guard Assembly
b1064a2x
1. Upper belt guard
2. Upper belt guard fasteners (3)
3. Lower belt guard fasteners (3)
4. Lower belt guard
5. Sprocket cover
6. Sprocket cover fasteners (2 short, 1 long)
2
5
6
1
4
3
6
