2005 Buell Firebolt: Maintenance 1-45
HOME
11. See Figure 1-44. Verify that the interactive exhaust cable
(1) is routed behind the frame lug (2) before installing air
intake cover.
CAUTION
If cable is routed in front of the frame lug it will cause the
muffler valve to stay open not allowing it to work prop-
erly.
12. Install air intake cover.
Figure 1-46. Correct Cable Routing Behind Frame Lug
10514a
1. Interactive exhaust cable
2. Frame lug
2
1
