Buell 2005 FIREBOLT - Trouble Code 35

2005 Buell Firebolt: Fuel System 4-77
HOME
TROUBLE CODE 35 4.25
GENERAL
Tachometer
A Code 35 will set if the PK tachometer wire is shorted to
power or ground.
DIAGNOSTICS
Diagnostic Notes
The reference numbers below correlate with the circled num-
bers on the Code 35 flow chart.
1. Connect BREAKOUT BOX (Part No. HD-42682) to ECM.
See 4.6 BREAKOUT BOX.
2. Replace instrument module. See 7.18 INSTRUMENT
MODULE.
Figure 4-53. Installed Breakout Box
Figure 4-54. Instrument Module Connector [39]
8427
1. ECM
2. Breakout box
1
2
8426
