2005 Buell Firebolt: Maintenance 1-49
HOME
ADJUSTMENT
HIGH beam and LOW beam have independent adjuster
screws.
See Figure 1-55. The HIGH Beam adjuster (1) is on the left
and the LOW Beam adjuster (2) is on the right underneath
the front fairing.
If headlamp requires adjustment, perform the following:
NOTE
●
To lower beam, turn adjuster clockwise.
●
To raise beam, turn adjuster counterclockwise.
Figure 1-55. Headlamp Height Adjustment
8392
1
2
1. High beam adjuster (left)
2. Low beam adjuster (right)
