3.1.2 Special functions
Height adjustment
Depending upon the bed model, the mattress base height can be adjusted
from approximately 25 to 80 cm.
During the height adjustment, continuous monitoring of the horizontal position
occurs – including when a strongly imbalanced load is acting on the mattress
base.
An “intermediate stop” is made when loweringat approx. 38 cm. This
makes getting into/out of bed easier. This height can be individually program-
med for each resident (see chapter
Part C: Saving a new “intermediate stop”
position » 11). If the mattress base is tilted, it automatically moves into a
horizontal position when it reaches the highest or lowest setting.
Sitting position
Initially, the backrest and thigh rest are raised (to an auto contour position).
The mattress base is then tilted to a reverse-Trendelenburg position.
Sleep position
If this button is kept pressed, the mattress base is adjusted to the following
positions in turn in the following order:
1. to a horizontal position
2. the backrest is lowered immediately – the thigh rest follows after a delay of
9 seconds
3. To the “intermediate stop” position (pre-set to approx. 38 cm).
Special functions Switch the under bed light on/off (optional)
Standard setting: The LED under bed light is active when connected to
the mains power supply.
Press the two buttons “Backrest UP” and “Backrest DOWN” at the same
time for about 3 seconds to manually switch the under bed light on or
off.
For further details, see chapter
Part C: Under bed light (optional equip-
ment) » 15.
Operation
10 Part C: Care staff and residents
