3.7.2 Removal
3.
Slightly raise the bed extension and push it forwards until the locking hooks on the bed
extension slide over the cross tube on the mattress base frame and are positioned over
the slits provided [A].
4. Press the bed extension down until the hooks snap into place.
5. Swivel the locking levers upwards (on the left and right-hand side) and press them in
until they audibly click into place
6.
Install the footboard (see Part B: Headboard and footboard » 15).
7.
Install the longer side panel and/or longer safety side (see Part B: Side panels » 18
and/or Part B: Full-length safety sides (DSG) » 24/Part B: Split safety sides » 27).
Proceed in reverse order to the installation process with the only difference: Pull the orange
safety lock [C] outwards with your finger and hold it in this position while tilting the locking
levers downwards [D].
Assembling the Care Bed
Part B: Operator and Technical Personnel 37
