CAUTION
4.3 Components of the Bed
4.3.1 Mattress base frame
4.3.2 Safety side (optional)
4.3.3 Electrical adjustment system
Risk of injury
Failure to heed this warning may result in physical injury to the resident due to entrapment
or crushing of limbs.
•
Owing to the smaller limbs of residents with a body height/weight that is less than this,
there is an increased risk of entrapment between the open spaces of the safety sides
when safety side systems are used.
The bed is delivered unassembled so that it can be transported to any room. It consists of a
chassis, a headboard, a footboard, a mattress base frame and the side panels. The bed is
equipped with four castors which are fitted with a locking brake
The mattress base frame is divided into a backrest, a fixed middle section, a thigh rest and a
lower leg rest. All rests are adjustable. The mattress base height can be adjusted horizontal-
ly. A handset controls all electrical adjustments. The entire mattress base and all parts of the
bed that can be reached by a resident who is lying in the bed count as application parts.
At the customer’s request, the bed can be equipped with safety sides to protect the resident
from falling out of bed. The safety sides can be raised from the lowered position beside the
mattress base to protect the resident.
The bed’s electrical adjustment system is first-error-secure, flame-resistant (V0) and consists
of:
•
An "external" switch mode power supply.
The switch mode power supply consists of: Voltage transformer and low voltage con-
nection cable. The voltage transformer generates a protective low voltage that is safe
for residents and users. The switch mode power supply provides all drives (motors)
