2.
The motors of the thigh rest and the back rest have been secured in transport position
by the manufacturer. They must first be removed from their transport position.
⁃
Remove the locking pin on the housing.
⁃
Cut through the cable tie on the drive tube.
Note: Pay attention to the cable routing. Place the motors with their locking pins
on the floor.
3. Connect the switch mode power supply, see Part A: Electrical connection dia-
gram » 16.
4. Move the chassis to the highest position.
Assembling the Care Bed
12 Part B: Operator and Technical Personnel
