3.6.3.3 Sticker – split safety sides (optional equipment)
WARNING
Fig. D
Risk of injury
Failure to heed this warning may result in physical injury due to entrapment.
•
Please note: There is a sticker in the middle of the long side of the mattress base frame
(see illustration). This sticker warns you not to attach two 90 cm long split safety sides to
one side of the bed. Doing so creates a gap between the two safety sides, which leads to
a risk of entrapment of limbs.
•
Only attach the permitted sizes of split safety sides per bed side (more on this on the next
page)
•
Observe the following table when installing split safety sides.
Assembly on beds without a
bed extension
Assembly on beds with a
bed extension (approx. 20
cm)
Per bed side
1x size 110 cm (head end/foot
end)
1x size 90 cm (head end/foot
end)
2x size 110 cm
Assembling the Care Bed
Part B: Operator and Technical Personnel 31
