Product Description | 2
Instruction Manual MINK MV 0500-0600 B_EN_en 5 | 40
Version: Pressure Control
IN
OUT
PSA2 OSG
ODP
NP
MTB
VSD
NRV
DA
CAI
CAO
EBOFP
PSA1
Description
IN Suction connection OUT Discharge connection
OFP Oil fill plug (=Venting valve) ODP Oil drain plug
CAI Cooling ait inlet CAO Cooling air outlet
OSG Oil sight glass NRV Non-return-valve (integrated)
MTB Motor terminal box VSD Variable speed drive
EB Eye bolt DA Directional arrow
PSA2 Pressure transmitter 2 NP Nameplate
PSA1 Pressure transmitter 1 (not shown) deliv-
ered loosely
NOTE
Technical term.
In this instruction manual, we consider that the term ‘machine’ refers to the ‘vacuum pump’.
NOTE
Illustrations
In this instruction manual, the illustrations may differ from the machine appearance.
