2 | Product Description
6 / 68 0870211676_RA0760A_PLUS_-0004_IM_en
Vacuum pump (VP)
OS IFOFP EF
TSAOF
GBPSA1 MOT
LS
PSA2
OSGODP
TS
EF Exhaust filter GB Gas ballast valve
IF Inlet filter LS Level switch (oil level)
MOT Motor (pump drive) OF Oil filter
ODP Oil drain plug OFP Oil fill plug
OS Oil separator OSG Oil sight glass
PSA1 Pressure transmitter
(inlet gas pressure)
PSA2 Pressure transmitter
(exhaust gas pressure in the oil separator)
TSA Resistance thermometer (oil temp.)
NOTE
Technical term.
In this instruction manual, we consider that the term ‘machine’ refers to the ‘vacuum
pump’.
NOTE
Illustrations
In this instruction manual the illustrations may differ from the machine appearance.
