Assembly & Operation Manual
BVM © 2009 K5300-Current_manual-090808.doc Page 56 12/2/2009
JR SERVO AND EXTENSION REQUIREMENTS
CONTROLS QTY SERVO TYPE QTY Channel LEAD
EXT
Ailerons 2 JR 9411 2 AIL
AUX 2
12”
2 36”
Elevators 2 JR 3421 2 ELEV
GEAR
48”
Rudder Swept or Std
Fin
1 JR 9411 1 RUDD 36”
Nose Steering 1 JR 9411 1 RUDD “Y”
Harness
Retract Valve 1 JR 351 AUX 5 N/A
Flaps 2 JR 8411 1 AUX 1 Match
Box
2 36”
2 3”
Smooth Stop 1 JR 368BB AUX 3 N/A
Battery 1 SPMB4000LP
1 SPMVR6010
NOTE: IF EQUIPMENT OTHER THAN JR IS USED, CONSULT THE MANUFACTURER FOR SIMILAR
COMPONENTS.
To make the Bandit ARF very easy to rig, we chose to put each servo on it’s own channel. This allows
easy adjustments and servo reversing to each flight control.
Simply download the JR data safe file if you plan to use our program layout.
The only difficult mix involved moves the gear channel to Aux 5.
*NOTE: Reverse servos and Y-harnesses are not required when 2 servos are used with a JR Match
Box.
The JR Match Box can also be used on rudder and nose gear steering to avoid any need for reversed
servos.
Radio manufacturers are constantly improving their equipment - consult their representatives or BVM (JR
only) for the latest and best servos.
