PERMA-GRIT AND SOME OTHER USEFUL TOOLS
Perma-Grit tools are sold in the USA by BVM. These are very high quality, tungsten carbide grit abrasive
tools that will make modeling easier.
TOOL LIST
2-56 tap
4-40 tap 2-flute
.050 Hex Driver BVM#2157
Perma-Grit small files BVM#NF-1
Large files are also handy (#LNF-1)
(2) X-Acto Razor Saw #235
Carbide Cutters (5/pk) BVM #2142
Set of ball end hex wrenches
Dremel drum sander
Dremel #409 cut-off discs and mandrel
A good set of small Phillips and slot end
screwdrivers
12" steel ruler with 1/10th inch scale
#43 (.089”) 4-40 tap drill
1/16” drill
Pin vise to hold 1/16” drill bit
Perma-Grit cut off Disc RD-2
Perma-Grit FXT-103
ABBREVIATIONS USED IN THIS MANUAL
CA Cyanoacrylate Adhesive LE Leading Edge
SHCS Socket Head Cap Screw TE Trailing Edge
SMS Sheet Metal Screw F/G Fiberglass
SHSS Socket Head Set Screw CG Center of Gravity
CF Carbon Fiber C/L Centerline
SHSMS Socket Head Sheet Metal Screw LC Laser Cut
BHSMS Button-Head Sheet Metal Screw BHMS Button-Head Machine Screw
WARNINGS
Use a particle mask such as 3M #6985 (available at auto paint stores) to protect from inhaling the
glass or carbon fiber dust. Use this mask whenever sanding or cutting fiberglass or carbon fiber
materials.
Use a professional charcoal filter paint mask (available at auto paint supply stores) when spraying
any primer or paint. Spray out of doors or in a properly vented spray booth.
Use safety glasses any time rotary tools, such as Dremel #409 disc or Perma-Grit cutters, are being
used.
