Assembly & Operation Manual
BVM © 2009 K5300-Current_manual-090808.doc Page 58 12/2/2009
K5300A-18 BA FLEX PLATES
Qty Needed Component ID Component Description
2 K5300M-RC019 CF, .084,Main Flexplate w/wash
2 K5300M-RC020 CF, .084, Main Flexplate Dblr
16 4029 BOLT 4-40 X 1/2 SHCS
K5300A-20 BA SERVO/EQP INSTALL PACKAGE
Qty Needed Component ID Component Description
8 4021 #4 FLAT WASHER
1 2865 #2 X 7/16" SSSH bag of 75
8 4138 BOLT 4-40 X 3/8 SHCS BLACK
2 W3381 3/8 X 5/8 X 3/4" MAPLE
2 W3386 3/8 X 1/2 X 3/4" MAPLE
4 PS-SP-0009 TEES FOR SERVOS
K5300A-21 CANOPY/DECK PACKAGE
Qty Needed Component ID Component Description
1 1727 SUPER BANDIT DASHBOARD
1 VF3006 BOBCAT COMP EJECTION SEAT
1 LC3294 1/8 BALSA SEAT BACK
1 4074 O-RING 1/16X1-1/4 BUNA
1 8049 I BEAM PLASTIC 8"
1 I7245 S BANDIT CANOPY/DECK INSTRUCTI
1 VF3918 SUPER BANDIT COCKPIT DECK
K5300A-22 BA NOSE GEAR DOOR ATTACH PKG
Qty Needed Component ID Component Description
1 2961 1/16 x 10" WIRE
1 2988 SPRING 1/8 x 1-1/4" EXT
1 W3418 1/4 X 3/8 X 5" MPL STICK
6 4051 DUBRO HINGE & PINS
1 4121 DOMED SMS 3/8 SOCKET
18 4121A #2 X 3/16 BUTTON HD SMS
2 MC5045 BVM STRUT DOOR ATTACHMENT
1 LC3297 1/8 5PLY NG DOOR ACTUATOR
