Notice technique ADOUCISSEUR A27-A6X - Manual SOFTENER A27-A6X code P0011144 - Rev 0 - 29/02/2016
INSTALLATION PROCEDURE
The numbers in bold refer to the marks in chapter INSTALLATION - OVERVIEW
Step Directions
Tighten the hydraulic block The preliminary tightening of the hydraulic block
upon the vessel is crucial because untightening
during transportation may have occurred.
Check the network pressure The pressure shall be between 1.5 et 7 bars.
Above 5 bars, install a pressure reducer.
Check the power outlet Check that there is a power outlet of 230 V at less
than 1.20 meters.
Insert a tap for non-softened water (14) In case you need to keep raw water (for example
for gardening, etc.)
Install the pre-fi lter (7) Place and connect the fi lter upstream from the
softener.
Comply with the water fl ow direction as shown
on the fi lter head.
Fix the fi lter head on the wall with the bracket,
without tightening too much the screws on the
fi lter head.
Install the by-pass (12)
Note: the shown by-pass is wall-mounted single
block brass by-pass
Install the bypass on the pipe complying with the
water fl ow direction.
Turn the bypass tap into the softener by-pass
position.
