BWT Infinity M - Flow Rate and Pressure Loss Data

25
25
EN
 

Flowrate[m³/h] 1 2 3 4 5 6 7 8 9
Pressureloss∆p[bar] 0.01 0.06 0.12 0.22 0.34 0.49 0.67 0.88 1.11

Flowrate[m³/h] 2 3 4 5 6 7 8 9 10
Pressureloss∆p[bar] 0.05 0.11 0.20 0.31 0.44 0.60 0.79 0.10 1.23

Flowrate[m³/h] 2 4 6 8 9 10 11 12 13
Pressureloss∆p[bar] 0.03 0.10 0.23 0.404 0.51 0.63 0.76 0.91 1.07

Flowrate[m³/h] 2 4 6 8 10 12 14 18 22
Pressureloss∆p[bar] 0.01 0.03 0.08 0.13 0.21 0.30 0.41 0.68 1.01

Flowrate[m³/h] 2 4 6 8 10 12 14 18 22
Pressureloss∆p[bar] 0.01 0.03 0.07 0.13 0.21 0.30 0.41 0.67 1
 
Thetypelabelservesasproductidentier.Incase
of any requests, please have the following infor-
mation ready:
1. Device name
2. Productionnumber(PNR)
3. Serialnumber(SNR)
The type label is an o󰀩cial document and
mustnotbe alteredor stripped o󰀨.Dama-
ged or unreadable type labels have to be
replaced.
