1-4 FlexNet
®
700 Series Line Extender Rev F
1
Based on the model options in Table 1.1, an E7 Line Extender with the part number, E72CJPA12C6D1,
has the following options:
■ 700 Series Line Extender—E7
■ 30dB PHD—2
■ 750MHz— C
■ 42/54MHz split— J
■ Lid-mounted power supply—P
■ TLC—A1
■ passive return—2
■ internal cable equalization of 4dB—C
■ 117V, UL/CSA power supply—6
■ 2 Port, 1 GHz, full lid housing with 117V powering—D
■ Standard Housing finish—1
Consult your C-COR Price List or contact your C-COR sales representative at 800-233-2267 for further
information.
Table 1.1 Part Number Designators (Model Options) for FlexNet
®
700 Series Line Extender
Designator Options
Part Number
E7 x x x x xx x x x x x
E7
FlexNet 700 Series PHD Line Extender Series
0
21 dB PHD
Spacing
1
28 dB PHD
2
30 dB PHD
3
33 dB PHD
5
32 dB PHD
7
35 dB PHD
C
750MHz
Bandwidth
D
862 MHz
J
42/54MHz
Frequency Split
L
40/54MHz
–
Integrated Power Supply
Module Designator
P
Lid-Mounted Power Supply
NA
None
Level Control
A1
TLC
KB
439.25 MHz TV
LO
499.25 MHz TV
1
None
Return
2
Passive
4
Standard Gain (18dB)
5
High Gain (20 dB)
C
F
4dB
15.5dB
Internal Cable Equalization
0
1
2
6
8
9
A
No Power Supply
60V, 60Hz
1.1 Amp 90V Transformerless with Time Delay
117V, UL/CSA
60V, 50/60Hz
1.0 Amp, 90V High Efficiency (H.E.) Transformerless
90V Transformered
Powering
A
D
K
L
None
2 Port, 1 GHz, Full Lid, 117V Powering
2 Port, 1 GHz, Full Lid
2 Port, 1 GHz, Flat Lid
Housing
1
4
Standard (or NA)
Corrosion Protected
Housing Finish
