C-TEC CAST XFP User Manual

CHANGE ADDRESS
This function is used to change device addresses at the panel, therefore saving the use of ladders to
access a device on site.
Note: The CAPROG Handheld Programmer can be used to manually change the address of a device, but
this will also require a loop learn to be carried out.
Enter AL3 (4444) > Commissioning Functions > Address Functions > Change Address.
When the CHANGE ADDRESS prompt is displayed press the Accept
4button and the following is
displayed:
Enter the address you want to change using the
5and6scroll buttons then press the Accept 4button.
The device’s LED will light and the following is displayed, for example ‘Device 8’.
Enter the new address of the device using the
5and6scroll buttons, for example ‘Device 9’, then press
the Accept
4button.
In this example the panel will auto-assign address 8 to address 9.
When requested by the panel fit the NVM link shown below:
Wait until the old address is flashing, address 8 is shown below.
Press Escape
3 button x 4. The panel will re-learn and a brief summary window will appear, similar to
the one shown below:
Press the Accept
4button then press Escape 3 button to return the panel to a normal condition.
When requested by the panel remove the NVM link shown below:
Old Address: 1
Loop : 1 Device : 8
New Address : 8
Loop : 1 Device : 8
New Address : 9
Please fit the NVM Link now
Old Address: ‘8’
112 Devices Found
Auto learn complete, Press Accept
6: 50 16 Jan : Normal
Remove the NVM Un-Lock link
CAST XFP 16 ZONE ANALOGUE ADDRESSABLE FIRE ALARM PANEL
ENGINEERING MANUAL • Approved Document No. DFU5010000 Rev 4 • Page 27 of 48
