2 Installation
2.2 Unpacking and Installing the Device
 Lift the label printer out of the carton by the straps.
 Check the label printer for any possible transportation damage.
 Check that the delivery is complete.
Delivery scope:
• Label printer
• Power cable
• USB cable
• Operator's Manual
• DVD with label software, Windows driver and documentation
i
Notice!
Please keep the original packaging in case the printer must be returned.
!
Attention!
The device and printing materials will be damaged by moisture and wetness.
 Set up label printers only in dry locations protected from splash water.
 Place the printer on a at surface.
2.3 Connecting the Device
The standard available interfaces and connectors are shown in gure 1, view A.
2.3.1 Connecting to the Power Supply
The printer is equipped with a wide area network unit. The device can be operated with a supply voltage of
230 V~/50 Hz or 115 V~/60 Hz without adjustment.
1. Check that the device is switched off.
2. Plug the power cable into the power connection socket (6).
3. Plug the power cable into a grounded socket.
2.3.2 Connecting to a Computer or Computer Network
!
Attention!
Inadequate or no grounding can cause malfunctions during operations.
Ensure that all computers and cables connected to the label printer are grounded.
 Connect the label printer to a computer or network by a suitable cable.
 For details of the conguration of the individual interfaces  the Conguration Manual.
2.4 Switching on the Device
When all connections have been made:
 Switch the printer on at the power switch (8).
The printer performs a system test, and then shows the system status ready in the display (17).
If an error occurs during the system test, the symbol
and type of error are displayed.
